ReadiLink™ xtra Rapid Cy7 Antibody Labeling Kit *BSA-Compatible*
Ordering information
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Additional ordering information
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Spectral properties
Correction Factor (260 nm) | 0.05 |
Correction Factor (280 nm) | 0.036 |
Correction Factor (482 nm) | 0.0005 |
Correction Factor (565 nm) | 0.0193 |
Correction Factor (650 nm) | 0.165 |
Extinction coefficient (cm -1 M -1) | 250000 |
Excitation (nm) | 756 |
Emission (nm) | 779 |
Quantum yield | 0.3 |
Storage, safety and handling
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
UNSPSC | 12171501 |
Related products
Overview | ![]() ![]() |
See also: Antibody and Protein Labeling, Immunophenotyping
Correction Factor (260 nm) 0.05 | Correction Factor (280 nm) 0.036 | Correction Factor (482 nm) 0.0005 | Correction Factor (565 nm) 0.0193 | Correction Factor (650 nm) 0.165 | Extinction coefficient (cm -1 M -1) 250000 | Excitation (nm) 756 | Emission (nm) 779 | Quantum yield 0.3 |
ReadiLink™ xtra rapid antibody labeling kits require essentially only 2 simple mixing steps without a column purification needed. Specially formulated Cy7 used in this ReadiLink™ kit is quite stable and shows good reactivity and selectivity with antibodies. The kit has all the essential components for labeling ~2x50 ug antibody. Each of the two vials of specially formulated Cy7 dye provided in the kit is optimized for labeling ~50 µg antibody. ReadiLink™ xtra Cy7 rapid antibody labeling kit provides a convenient and robust method to label monoclonal and polyclonal antibodies with NIR fluorescent Cy7 fluorophore. Cy7 is one of the most used fluorophores for labeling antibodies.
![readilinkworkflow](https://images.aatbio.com/universal/catalog/AntibodyProteinLabeling/readilinkworkflownew.png)
Figure 1. Overview of the ReadiLink™ xtra Rapid Antibody Labeling protocol. In just two simple steps, and with no purification necessary, covalently label microgram amounts of antibodies in under an hour.
Components
Example protocol
AT A GLANCE
Important
Warm all the components and centrifuge the vials briefly before opening, and immediately prepare the required solutions before starting your conjugation. The following protocol is for recommendation.PREPARATION OF WORKING SOLUTION
Protein working solution (Solution A)
For labeling 50 µg of protein (assuming the target protein concentration is 1 mg/mL), mix 5 µL (10% of the total reaction volume) of Reaction Buffer (Component B) with 50 µL of the target protein solution.Note If you have a different protein concentration, adjust the protein volume accordingly to make ~50 µg of protein available for your labeling reaction.
Note For labeling 100 µg of protein (assuming the target protein concentration is 1 mg/mL), mix 10 µL (10% of the total reaction volume) of Reaction Buffer (Component B) with 100 µL of the target protein solution.
Note The protein should be dissolved in 1X phosphate buffered saline (PBS), pH 7.2 - 7.4; if the protein is dissolved in glycine buffer, it must be dialyzed against 1X PBS, pH 7.2 - 7.4, or use Amicon Ultra-0.5, Ultracel-10 Membrane, 10 kDa (cat# UFC501008 from Millipore) to remove free amines or ammonium salts (such as ammonium sulfate and ammonium acetate) that are widely used for protein precipitation.
Note Impure antibodies or antibodies stabilized with bovine serum albumin (BSA) with 0.1 to 0.5 % will be labeled well.
Note For optimal labeling efficiency, a final protein concentration range of 1 - 2 mg/mL is recommended, with a significantly reduced conjugation efficiency at less than 1 mg/mL.
SAMPLE EXPERIMENTAL PROTOCOL
Run conjugation reaction
- Add the protein working solution (Solution A) to ONE vial of labeling dye (Component A), and mix them well by repeatedly pipetting for a few times or vortex the vial for a few seconds.
Note If labeling 100 µg of protein, use both vials (Component A) of labeling dye by dividing the 100 µg of protein into 2 x 50 µg of protein and reacting each 50 µg of protein with one vial of labeling dye. Then combine both vials for the next step. - Keep the conjugation reaction mixture at room temperature for 30 - 60 minutes.
Note The conjugation reaction mixture can be rotated or shaken for longer time if desired.
Stop Conjugation reaction
- Add 5 µL (for 50 µg protein) or 10 µL (for 100 µg protein) which is 10% of the total reaction volume of TQ™-Dyed Quench Buffer (Component C) into the conjugation reaction mixture; mix well.
- Incubate at room temperature for 10 minutes. The labeled protein (antibody) is now ready to use.
Storage of Protein Conjugate
The protein conjugate should be stored at > 0.5 mg/mL in the presence of a carrier protein (e.g., 0.1% bovine serum albumin). For longer storage, the protein conjugates could be lyophilized or divided into single-used aliquots and stored at ≤ –20 °C.Spectrum
Open in Advanced Spectrum Viewer
![spectrum](/_next/image?url=https%3A%2F%2Fimages.aatbio.com%2Fspectra%2Fcy7_cyanine_7.png&w=2048&q=50)
![spectrum](/_next/image?url=https%3A%2F%2Fimages.aatbio.com%2Fspectra%2Fcy7_cyanine_7.png&w=2048&q=50)
Spectral properties
Correction Factor (260 nm) | 0.05 |
Correction Factor (280 nm) | 0.036 |
Correction Factor (482 nm) | 0.0005 |
Correction Factor (565 nm) | 0.0193 |
Correction Factor (650 nm) | 0.165 |
Extinction coefficient (cm -1 M -1) | 250000 |
Excitation (nm) | 756 |
Emission (nm) | 779 |
Quantum yield | 0.3 |
Product Family
Images
![Immunofluorescence staining of tubulin in HeLa cells. HeLa cells were fixed with 4% PFA, permeabilized with 0.1% Triton X-100 and blocked. Cells were then incubated with mouse anti-tubulin antibody and stained with a goat anti-mouse IgG labeled using the ReadiLink™ xtra Rapid Cy7 Antibody Labeling Kit (Cat No. 1973).](/_next/image?url=https%3A%2F%2Fimages.aatbio.com%2Fproducts%2Ffigures-and-data%2Freadilink-xtra-rapid-cy7-antibody-labeling-kit-bsa-compatible%2Ffigure-for-readilink-xtra-rapid-cy7-antibody-labeling-kit-bsa-compatible_1NvBi.jpg&w=3840&q=75)
Figure 1. Immunofluorescence staining of tubulin in HeLa cells. HeLa cells were fixed with 4% PFA, permeabilized with 0.1% Triton X-100 and blocked. Cells were then incubated with mouse anti-tubulin antibody and stained with a goat anti-mouse IgG labeled using the ReadiLink™ xtra Rapid Cy7 Antibody Labeling Kit (Cat No. 1973).
![HeLa cells were fixed with 4% PFA, permeabilized and blocked. Cells were then incubated with (red) or without (green) anti-beta 2 rabbit antibody and stained with a goat anti-rabbit IgG labeled using the ReadiLink™ xtra Rapid Cy7 Antibody Labeling Kit (Cat No. 1973). The fluorescence signal was monitored using an ACEA NovoCyte flow cytometer in the APC-Cy7 channel.](/_next/image?url=https%3A%2F%2Fimages.aatbio.com%2Fproducts%2Ffigures-and-data%2Freadilink-xtra-rapid-cy7-antibody-labeling-kit-bsa-compatible%2Ffigure-for-readilink-xtra-rapid-cy7-antibody-labeling-kit-bsa-compatible_Bbmzb.jpg&w=3840&q=75)
Figure 2. HeLa cells were fixed with 4% PFA, permeabilized and blocked. Cells were then incubated with (red) or without (green) anti-beta 2 rabbit antibody and stained with a goat anti-rabbit IgG labeled using the ReadiLink™ xtra Rapid Cy7 Antibody Labeling Kit (Cat No. 1973). The fluorescence signal was monitored using an ACEA NovoCyte flow cytometer in the APC-Cy7 channel.
