Phalloidin Conjugates
Phalloidin conjugates stain F-actin in fixed and permeabilized cells with high-affinity.
Phalloidin is a bicyclic heptapeptide isolated from the poisonous death cap mushroom, Amanita phalloides. Its high binding affinity for the grooves between filamentous actin (F-actin) over monomeric G-actin is widely used to visualize and quantitate F-actin in tissue sections, cell cultures, or cell-free preparations. Compared to actin-specific antibodies, the non-specific binding of phalloidin is negligible, thus providing minimal background and high contrast during cellular imaging. Once bound to F-actin, phalloidin shifts the equilibrium of monomers and filaments toward the filaments side and inhibits ATP-hydrolysis. The interaction stabilizes actin filaments by preventing subunit dissociation, and it promotes actin polymerization by lowering the critical concentration.
When conjugated to fluorescent dyes, phalloidin can be used at nanomolar concentrations to label and visualize F-actin in fixed and permeabilized cells, cell cultures, and cell-free experiments, as well as formaldehyde-fixed and permeabilized tissue sections. Phalloidin conjugates exhibit similar affinity for all types and sizes of actin filaments, binding in a stoichiometric ratio of 1:1 (phallotoxin:actin) in both muscle and nonmuscle cells. Compared to antibodies, phalloidin derivatives' are small (< 2 kDa), and phalloidin-bound filaments do not impede the functional properties of the filaments. The small size also permits denser F-actin labeling producing more detailed stains when imaged at higher resolutions. In addition, because actin is evolutionarily conserved, the binding properties of phalloidin derivatives can be utilized in staining a wide range of animal and plant cells.
Example protocol
AT A GLANCE
- Prepare samples in microplate wells
- Remove liquid from samples in the plate
- Add Phalloidin-iFluor™ 488 Conjugate solution (100 μL/well)
- Stain the cells at room temperature for 20 to 90 minutes
- Wash the cells
- Examine the specimen under microscope with FITC filter
Note Phalloidin is toxic, although the amount of toxin present in a vial could be lethal only to a mosquito (LD50 of phalloidin = 2 mg/kg), it should be handled with care.
PREPARATION OF WORKING SOLUTION
Note The stock solution of phalloidin conjugate should be aliquoted and stored at -20 °C. protected from light.
Note Different cell types might be stained differently. The concentration of phalloidin conjugate working solution should be prepared accordingly.
SAMPLE EXPERIMENTAL PROTOCOL
- Perform formaldehyde fixation. Incubate cells with 3.0–4.0 % formaldehyde in PBS at room temperature for 10–30 minutes.
Note Avoid any methanol containing fixatives since methanol can disrupt actin during the fixation process. The preferred fixative is methanol-free formaldehyde. - Rinse the fixed cells 2–3 times in PBS.
- Optional: Add 0.1% Triton X-100 in PBS into fixed cells for 3 to 5 minutes to increase permeability. Rinse the cells 2–3 times in PBS.
- Add 100 μL/well (96-well plate) of Phalloidin-iFluor™ 488 Conjugate working solution into the fixed cells, and stain the cells at room temperature for 20 to 90 minutes.
- Rinse cells gently with PBS 2 to 3 times to remove excess phalloidin conjugate before plating, sealing and imaging under microscope with FITC filter set.
Spectrum
Product family
Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) | Quantum yield | Correction Factor (260 nm) | Correction Factor (280 nm) |
Phalloidin-iFluor® 350 Conjugate | 345 | 450 | 200001 | 0.951 | 0.83 | 0.23 |
Phalloidin-iFluor® 405 Conjugate | 403 | 427 | 370001 | 0.911 | 0.48 | 0.77 |
Phalloidin-iFluor® 514 Conjugate | 511 | 527 | 750001 | 0.831 | 0.265 | 0.116 |
Phalloidin-iFluor® 532 Conjugate | 537 | 560 | 900001 | 0.681 | 0.26 | 0.16 |
Phalloidin-iFluor® 555 Conjugate | 557 | 570 | 1000001 | 0.641 | 0.23 | 0.14 |
Phalloidin-iFluor® 594 Conjugate | 587 | 603 | 2000001 | 0.531 | 0.05 | 0.04 |
Phalloidin-iFluor® 633 Conjugate | 640 | 654 | 2500001 | 0.291 | 0.062 | 0.044 |
Phalloidin-iFluor® 647 Conjugate | 656 | 670 | 2500001 | 0.251 | 0.03 | 0.03 |
Phalloidin-iFluor® 680 Conjugate | 684 | 701 | 2200001 | 0.231 | 0.097 | 0.094 |
Show More (4) |
Citations
Authors: Vinnikova, Olha and Drofa, Anna and Raievska, Iryna
Journal: Problems of Cryobiology and Cryomedicine (2024): 125--142
Authors: Yu, Chenghao and Chen, Jinli and Wang, Tianrui and Wang, Yawen and Zhang, Xiaopei and Zhang, Zhuoli and Wang, Yuanfei and Yu, Tengbo and Wu, Tong
Journal: Journal of Nanobiotechnology (2024): 696
Authors: Lamparelli, EP and Marino, M and Scognamiglio, MR and D’Auria, R and Santoro, A and Della Porta, G
Journal: International Journal of Pharmaceutics (2024): 124934
Authors: Yu, Junhui and Chen, Xing and Ding, Xiaoxiao and Lin, Kang and Zhang, Tianxin and Wang, Kai
Journal: Biology Direct (2024): 105
Authors: Ar{\i}c{\i}, {\c{S}}ule and Kamali, Ali and Ege, Duygu
Journal: Biofabrication (2024)
References
Authors: Diensthuber RP, Muller M, Heissler SM, Taft MH, Chizhov I, Manstein DJ.
Journal: FEBS Lett (2011): 767
Authors: Lin G, Qiu X, F and el TM, Albersen M, Wang Z, Lue TF, Lin CS.
Journal: Urology (2011): 970 e1
Authors: Chazotte B., undefined
Journal: Cold Spring Harb Protoc (2010): pdb prot4947
Authors: An M, Wijesinghe D, Andreev OA, Reshetnyak YK, Engelman DM.
Journal: Proc Natl Acad Sci U S A (2010): 20246
Authors: Herraez E, Macias RI, Vazquez-Tato J, Vicens M, Monte MJ, Marin JJ.
Journal: Toxicol Appl Pharmacol (2009): 13
