MitoDNA™ Red 680
Price | |
Catalog Number | |
Unit Size | |
Quantity |
Telephone | 1-800-990-8053 |
Fax | 1-800-609-2943 |
sales@aatbio.com | |
International | See distributors |
Bulk request | Inquire |
Custom size | Inquire |
Shipping | Standard overnight for United States, inquire for international |
Molecular weight | 486.44 |
Solvent | DMSO |
Excitation (nm) | 597 |
Emission (nm) | 681 |
H-phrase | H303, H313, H333 |
Hazard symbol | XN |
Intended use | Research Use Only (RUO) |
R-phrase | R20, R21, R22 |
Storage | Freeze (< -15 °C); Minimize light exposure |
UNSPSC | 12171501 |
Overview | ![]() ![]() |
Molecular weight 486.44 | Excitation (nm) 597 | Emission (nm) 681 |
Platform
Fluorescence microscope
Excitation | 600 nm |
Emission | 680 nm |
Recommended plate | Black wall/clear bottom |
Example protocol
AT A GLANCE
Before using MitoDNA™ Red 680 for the first time, allow it to thaw at room temperature. Then, briefly centrifuge it to collect the dried pellet.
Prepare cells in a growth medium.
Stain cells with MitoDNA™ Red 680 working solution.
Incubate samples for 5 to 15 minutes at 37 °C.
Monitor fluorescence intensity at Ex/Em = 600/680 nm.
PREPARATION OF STOCK SOLUTIONS
Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles
Prepare a 5 to 10 mM MitoDNA™ Red 680 stock solution in DMSO. For example, add 205 μL of DMSO to the MitoDNA™ Red 680 vial to create a 10 mM stock solution.
Note: Prepare a single aliquot of the unused MitoDNA™ Red 680 stock solution and store it at ≤ -20 º C, protected from light. Avoid repeated freeze-thaw cycles.
PREPARATION OF WORKING SOLUTION
Prepare a 5 to 10 μM working solution by diluting the MitoDNA™ Red 680 stock solution in Hanks' solution with 20 mM HEPES buffer (HHBS).
Note: For optimal results, use this solution within a few hours of preparation.
Note: Cover the working solution with foil or store it in a dark place to protect it from light.
SAMPLE EXPERIMENTAL PROTOCOL
Plate the cells in a 96-well plate with black walls and a clear bottom.
Remove the cell culture medium and add 100 µL of MitoDNA™ Red 680 working solution directly to the cells.
Incubate the cells at 37°C for 5-15 minutes, protected from light.
Note: The concentration and incubation time of MitoDNA™ Red 680 may vary depending on the cell line. Test different concentrations to determine the optimal dose.
Remove the dye working solution and wash the cells twice with HHBS buffer.
Add HHBS buffer and analyze the cells using a fluorescence microscope with excitation/emission settings of 600/680 nm.
Calculators
Common stock solution preparation
0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
1 mM | 205.575 µL | 1.028 mL | 2.056 mL | 10.279 mL | 20.558 mL |
5 mM | 41.115 µL | 205.575 µL | 411.15 µL | 2.056 mL | 4.112 mL |
10 mM | 20.558 µL | 102.788 µL | 205.575 µL | 1.028 mL | 2.056 mL |
Molarity calculator
Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
/ | = | x | = |
Images
References
Authors: Yu, Chenxiao and Asadian, Samieh and Tigano, Marco
Journal: Human molecular genetics (2024): R12-R18
Authors: Kremer, Laura S and Rehling, Peter
Journal: Human molecular genetics (2024): R47-R52
Authors: Jin, Panpan and Tian, Yu and Zang, Erhuan and Zeng, Lingchao and Zhang, Zhaolei and Liu, Jinxin and Shi, Linchun
Journal: Mitochondrial DNA. Part B, Resources (2024): 652-656
Authors: Rucci, Chiara and de Simone, Gaia and Salathia, Saniya and Casadidio, Cristina and Censi, Roberta and Bordoni, Laura
Journal: FASEB journal : official publication of the Federation of American Societies for Experimental Biology (2024): e23672
Authors: Jeong, Jiyoon and Lee, Yeonmi and Han, Jongsuk and Kang, Eunju and Kim, Deokhoon and Kim, Ki-Soo and Kim, Ellen Ai-Rhan and Lee, Byong Sop and Jung, Euiseok
Journal: Gene (2024): 148337
Authors: Zhang, Yiqin and Ye, Jing and Zhou, Lina and Xuan, Xianfa and Xu, Liping and Cao, Xia and Lv, Tianyu and Yan, Jianhua and Zhang, Siyu and Wang, Yuxin and Huang, Qingyu and Tian, Meiping
Journal: Metallomics : integrated biometal science (2024)
Authors: Moraes, Carlos T
Journal: Human molecular genetics (2024): R92-R99
Authors: Fu, Yimin and Tao, Lei and Wang, Xiaojun and Wang, Binyou and Qin, Weilin and Song, Lei
Journal: Experimental gerontology (2024): 112428
Authors: Fang, Chanlin and Di, Shanshan and Yu, Yundong and Qi, Peipei and Wang, Xinquan and Jin, Yuanxiang
Journal: Journal of hazardous materials (2024): 134357
Authors: Shi, Panxing and Wang, Bingyi and Shi, Sirong and Chu, Xiaoge and Liu, Chen and Kang, Meijuan and Hui, Jingni and Gou, Yifan and Zhou, Ruixue and Liu, Ye and Jia, Yumeng and Zhang, Feng and Wen, Yan
Journal: European archives of psychiatry and clinical neuroscience (2024)
