Streptavidin-Xtra™ IF647

Streptavidin conjugates are widely used in combing with biotin conjugates for detecting a variety of biological targets such as proteins, nucleic acids and other molecules. They are used as an ideal choice for many biological detections such as immunofluorescence microscopy, flow cytometry, western blot and other biological applications since streptavidin has a strong affinity binding biotin which is not affected over a broad range of pH and temperature. AAT Bioquest® offers a variety of streptavidin conjugates labeled with the classic fluorescent dyes (for example: FITC, TRITC, Texas Red®, Cy3®, Cy5® and Cy7®) and also our superior water soluble, photostable iFluor® and mFluor™ dyes. However, the conventional biotin-avidin detection systems are still limited by the limited signal intensity of the existing fluorescent conjugates. The Streptavidin Xtra™ iFluor conjugates are a new family of super bright streptavidin conjugates with nearly identical excitation and emission properties to Alexa Fluor fluorophores with 3~5 folds signal improvement. It is a set of powerful tools to detect low abundance targets in cell imaging or flow cytometry.

Example protocol

PREPARATION OF STOCK SOLUTIONS

Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles

Streptavidin-Xtra™ IF647 stock solution (1 mg/mL)
  1. Add 100 µL (For Cat# 46006) or 1 mL (For Cat# 46007) of ddH2O to the vial to make a 1 mg/mL stock solution.

    Note: This constituted stock solution will be in PBS with 0.2% BSA.

PREPARATION OF WORKING SOLUTION

Streptavidin-Xtra™ working solution
  1. For IF, the suggested staining concentration is 1-5 ug/ml. For FACS, the suggested concentration is at 0.1-0.5 ug / 100 uL / million cells in the staining buffer.

    Note: PBS + 0.1% BSA can be used as a staining buffer.

    Note: For the best performance of each application, the optimal concentration of this reagent needs to be carefully determined.

    Note: The suggested working dilution is provided as a guide only. It is recommended that the users titrate the product in their tests using proper positive and negative controls.

SAMPLE EXPERIMENTAL PROTOCOL

  1. Block and treat the samples with antibodies of interest as per the manufacturer's recommendations.
  2. Add biotin-conjugated secondary antibody working solution in the samples at appropriate concentration and duration.]

    Note: Please verify the compatibility and type of your biotin-conjugated antibody with the primary antibody used in the experiment. For example, If the primary antibody is a mouse antibody, then a goat Anti-Mouse antibody bound with biotin can be used for the assay.

  3. Incubate the cells with Streptavidin-Xtra™ working solution at room temperature for 30 minutes to 1 hour. Note: Optimal time for incubation needs to be determined carefully.
  4. Remove the working solution and resuspend the cells in your choice of buffer.
  5. Take the image using the fluorescence microscope or record the intensity using flow cytometer.

Spectrum

Product family

NameExcitation (nm)Emission (nm)Extinction coefficient (cm -1 M -1)Quantum yieldCorrection Factor (260 nm)Correction Factor (280 nm)
Streptavidin-Xtra™ IF4884915167500010.910.210.11
Streptavidin-Xtra™ IF55555757010000010.6410.230.14
Streptavidin-Xtra™ IF59456858710000010.5710.340.15

Citations

View all 36 citations: Citation Explorer
Preexisting antibodies targeting SARS-CoV-2 S2 cross-react with commensal gut bacteria and impact COVID-19 vaccine induced immunity
Authors: Jia, Liqiu and Weng, Shufeng and Wu, Jing and Tian, Xiangxiang and Zhang, Yifan and Wang, Xuyang and Wang, Jing and Yan, Dongmei and Wang, Wanhai and Fang, Fang and others,
Journal: Gut microbes (2022): 2117503
Highly sensitive electrochemical biosensor for streptavidin detection based on CdSe quantum dots
Authors: Wei, Y. P., Liu, X. P., Mao, C. J., Niu, H. L., Song, J. M., Jin, B. K.
Journal: Biosens Bioelectron (2018): 99-103
Efficient streptavidin-functionalized nitrogen-doped graphene for the development of highly sensitive electrochemical immunosensor
Authors: Yang, Z., Lan, Q., Li, J., Wu, J., Tang, Y., Hu, X.
Journal: Biosens Bioelectron (2017): 312-318
High-sensitive surface plasmon resonance microRNA biosensor based on streptavidin functionalized gold nanorods-assisted signal amplification
Authors: Hao, K., He, Y., Lu, H., Pu, S., Zhang, Y., Dong, H., Zhang, X.
Journal: Anal Chim Acta (2017): 114-120
Correction to Peptide Tag-Induced Horseradish Peroxidase-Mediated Preparation of a Streptavidin-Immobilized Redox-Sensitive Hydrogel
Authors: Mishina, M., Minamihata, K., Moriyama, K., Nagamune, T.
Journal: Biomacromolecules (2017): 311
Page updated on December 17, 2024

Ordering information

Price
Unit size
100 ug
1 mg
Catalog Number
4600646007
Quantity
Add to cart

Additional ordering information

Telephone1-800-990-8053
Fax1-800-609-2943
Emailsales@aatbio.com
InternationalSee distributors
Bulk requestInquire
Custom sizeInquire
Technical SupportContact us
Purchase orderSend to sales@aatbio.com
ShippingStandard overnight for United States, inquire for international
Request quotation

Spectral properties

Correction Factor (260 nm)

0.03

Correction Factor (280 nm)

0.03

Correction Factor (656 nm)

0.0793

Extinction coefficient (cm -1 M -1)

2500001

Excitation (nm)

656

Emission (nm)

670

Quantum yield

0.251

Storage, safety and handling

Intended useResearch Use Only (RUO)

Platform

Flow cytometer

Excitation633 nm laser
Emission660, 20 nm filter
Instrument specification(s)APC channel

Fluorescence microscope

ExcitationCy5 filter set
EmissionCy5 filter set
Recommended plateBlack wall, clear bottom
Images of Hela cells stained with Streptavidin-Xtra&trade; iFluor® conjugates and Streptavidin Alexa Fluor &trade; conjugate.<br />Hela cells were fixed with 4% paraformaldehyde for 30 minutes, permeabilized with 0.02% Triton&trade; X-100 for 10 minutes, and blocked with 1% BSA for 1 hour. Fixed Hela cells were then stained with 1 &micro;g/mL alpha Tubulin Mouse Monoclonal Antibody for 1 hour at room temperature, followed by GxM IgG-biotin (Cat# 16729) stain and then visualized with Streptavidin-Xtra&trade; iFluor 647 and Streptavidin-Alexa Fluor&trade; 647. &nbsp;Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17535).
Images of Hela cells stained with Streptavidin-Xtra&trade; iFluor® conjugates and Streptavidin Alexa Fluor &trade; conjugate.<br />Hela cells were fixed with 4% paraformaldehyde for 30 minutes, permeabilized with 0.02% Triton&trade; X-100 for 10 minutes, and blocked with 1% BSA for 1 hour. Fixed Hela cells were then stained with 1 &micro;g/mL alpha Tubulin Mouse Monoclonal Antibody for 1 hour at room temperature, followed by GxM IgG-biotin (Cat# 16729) stain and then visualized with Streptavidin-Xtra&trade; iFluor 647 and Streptavidin-Alexa Fluor&trade; 647. &nbsp;Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17535).
Images of Hela cells stained with Streptavidin-Xtra&trade; iFluor® conjugates and Streptavidin Alexa Fluor &trade; conjugate.<br />Hela cells were fixed with 4% paraformaldehyde for 30 minutes, permeabilized with 0.02% Triton&trade; X-100 for 10 minutes, and blocked with 1% BSA for 1 hour. Fixed Hela cells were then stained with 1 &micro;g/mL alpha Tubulin Mouse Monoclonal Antibody for 1 hour at room temperature, followed by GxM IgG-biotin (Cat# 16729) stain and then visualized with Streptavidin-Xtra&trade; iFluor 647 and Streptavidin-Alexa Fluor&trade; 647. &nbsp;Cell nuclei were stained with Hoechst 33342 (Blue, Cat#17535).
