Nucleus
The cell nucleus is a membrane-bound organelle that contains most of the cell's genetic material (DNA) in the form of chromosomes. The main components of the nucleus include the nuclear envelope, a double membrane that encloses the entire organelle and isolates its contents from the cytoplasm, and the nuclear matrix, a network within the nucleus that adds mechanical support. Its primary functions include controlling gene expression, regulating DNA replication, and preserving the integrity of the DNA it houses.
Visualizing the cell nucleus either by fluorescence microscopy or flow cytometry is frequently done using high-affinity nucleic acid dyes. Before binding to DNA or RNA, the intrinsic fluorescence of these dyes are minimal, and once bound, its fluorescence intensity enhances significantly. Nucleic acid dyes are available in membrane-permeant and impermeant formats for live and dead cell analysis and quantification and in various wavelengths to support multiplex and colocalization studies with other fluorescent probes.
Visualizing the cell nucleus either by fluorescence microscopy or flow cytometry is frequently done using high-affinity nucleic acid dyes. Before binding to DNA or RNA, the intrinsic fluorescence of these dyes are minimal, and once bound, its fluorescence intensity enhances significantly. Nucleic acid dyes are available in membrane-permeant and impermeant formats for live and dead cell analysis and quantification and in various wavelengths to support multiplex and colocalization studies with other fluorescent probes.
Membrane Permeant Nucleic Acid Dyes
Membrane permeant nucleic acid dyes can be used to label both live cells with healthy intact cell membranes and cells with compromised membranes such as dead, fixed, or permeabilized cells. The overall toxicity of these dyes is relatively low with minimal effect on cell functionality, allowing for live cells to be tracked during stages of development and cellular processes such as mitosis and meiosis or as a suitable counterstain in live cells. Examples of cell-permeant nucleic acid dyes include Hoechst dyes and AAT Bioquest's Nuclear Violet™ LCS1, Nuclear Green™ LCS1, Nuclear Orange™ LCS1, and Nuclear Red™ LCS1/LCS2 dyes.
Membrane Permeant Nucelic acid dyes
Table 1. Membrane permeant nucleic acid stains for labeling the nucleus in live, dead and fixed cell.
Product name ▲ ▼ | Cell Permeability ▲ ▼ | Live/Fixed Cells ▲ ▼ | Ex/Em (nm) ▲ ▼ | Filter Set ▲ ▼ | Unit Size ▲ ▼ | Cat No. ▲ ▼ |
Hoechst 33342 *20 mM solution in water* | Membrane permeant | Live and fixed cells | 352/454 | DAPI | 5 mL | 17535 |
DAPI *10 mM solution in water* | Membrane permeant | Live and fixed cells | 359/457 | DAPI | 2 mL | 17507 |
Nuclear Blue™ LCS1 | Membrane permeant | Live and fixed cells | 353/456 | DAPI | 0.5 mL | 17559 |
Nuclear Violet™ LCS1 | Membrane permeant | Live and fixed cells | 400/458 | DAPI | 0.5 mL | 17543 |
Nuclear Yellow | Membrane permeant | Live and fixed cells | 368/501 | FITC | 25 mg | 17539 |
CYTO-13 *5 mM DMSO solution* | Membrane permeant | Live and fixed cells | 486/511 | FITC | 0.5 mL | 17553 |
CYTO-13 | Membrane permeant | Live and fixed cells | 486/511 | FITC | 5 mg | 17554 |
Nuclear Green™ LCS1 | Membrane permeant | Live and fixed cells | 501/526 | FITC | 0.5 mL | 17540 |
Nuclear Orange™ LCS1 | Membrane permeant | Live and fixed cells | 512/554 | TRITC | 0.5 mL | 17541 |
Hexidium Iodide *CAS 211566-66-4* | Membrane permeant | Live and fixed cells | 518/600 | Texas Red | 5 mg | 17562 |
Membrane Impermeant Nucleic Acid Dyes
Membrane impermeant nucleic acid dyes are used to label the nuclei of cells with compromised plasma membranes. These include dead, fixed, or permeabilized cells. Since cell-impermeant nucleic acid dyes cannot label live cells. They are frequently used in cell viability studies as a dead cell indicator or as a nuclear counterstain in colocalization or immunolabeling applications. Examples of cell-impermeant nucleic acid dyes include DAPI, propidium iodide (PI), 7-aminoactinomycin D (7-AAD), Nuclear Blue™ DCS1, Nuclear Green™ DCS1, Nuclear Orange™ DCS1, and Nuclear Red™ DCS1. Cyanine dimer dyes - DiTO™, DiYO™, and TWO-PRO™ - also display exceptional sensitivity for nucleic acids, including double-stranded DNA (dsDNA), single-stranded DNA (ssDNA), and RNA. These symmetric dimmers of cyanine dyes exhibit a 100 to 1000-fold fluorescence enhancement upon nucleic acid binding, and their molar extinction coefficients are an order magnitude greater than ethidium homodimers.
Table 2. Membrane impermeant nucleic acid stains for labeling the nucleus in dead and fixed cells.
Product name ▲ ▼ | Cell Permeability ▲ ▼ | Live/Fixed Cells ▲ ▼ | Ex/Em (nm) ▲ ▼ | Filter Set ▲ ▼ | Unit Size ▲ ▼ | Cat No. ▲ ▼ |
Nuclear Blue™ DCS1 | Membrane impermeant | Dead and fixed cells | 344/465 | DAPI | 0.5 mL | 17548 |
DiYO™-1 [equivalent to YOYO®-1] | Membrane impermeant | Dead and fixed cells | 491/508 | FITC | 1 mg | 17575 |
Nuclear Green™ DCS1 | Membrane impermeant | Dead and fixed cells | 501/526 | FITC | 0.5 mL | 17550 |
Nuclear Green™ Photo-Fixable DCS1 *5 mM DMSO Solution* | Membrane impermeant | Dead, fixed, & apoptotic cells | 502/527 | FITC | 1 mg | 17570 |
DiTO™-1 [equivalent to TOTO®-1] | Membrane impermeant | Dead and fixed cells | 514/531 | FITC | 0.2 mL | 17575 |
TWO-PRO™ 1 [equivalent to TO-PRO®-1] | Membrane impermeant | Dead and fixed cells | 515/531 | FITC | 0.2 mL | 17571 |
Nuclear Orange™ DCS1 | Membrane impermeant | Dead and fixed cells | 512/554 | TRITC | 0.5 mL | 17551 |
Propidium Iodide *CAS 25535-16-4* | Membrane impermeant | Dead and fixed cells | 537/618 | Texas Red | 5 g | 17516 |
Propidium Iodide *10 mM aqueous solution* | Membrane impermeant | Dead and fixed cells | 537/618 | Texas Red | 1 mL | 17517 |
DiYO™-3 [equivalent to YO-YO®-3] | Membrane impermeant | Dead and fixed cells | 612/631 | Cy5 | 0.2 mL | 17580 |
Product ordering information
Table 3. Ordering Info for Nuclear Labeling Products
Product Name ▲ ▼ | Unit Size ▲ ▼ | Cat# ▲ ▼ |
Pyronin Y *CAS 92-32-0* | 100 mg | 61 |
Stain-All *CAS 7423-31-6* | 25 mg | 10050 |
7-AAD [7-Aminoactinomycin D] *CAS 7240-37-1* | 1 mg | 17501 |
Acridine orange | 100 mg | 17502 |
Acridine orange *10 mg/mL solution in water* | 10 mL | 17503 |
Thiazole orange *CAS 107091-89-4* | 100 mg | 17518 |
Thiazole orange *10 mM in DMSO* | 10 mL | 17519 |
Actinomycin D | 5 mg | 17505 |
DAPI [4,6-Diamidino-2-phenylindole, dihydrochloride] *10 mM solution in water* | 2 mL | 17507 |
DAPI Dilactate | 25 mg | 17509 |
