Tubulite™ Red *Cell-Permeable*
Tubulite™ Red is a robust tool for fluorescent visualization of tubulin structures in live cells. This cell-permeable probe enables real-time imaging of tubulin dynamics, bypassing the need for cell fixation and allowing continuous assessment of tubulin polymerization and organization. The probe’s red fluorescence and high cellular permeability facilitate its use in multiplexed imaging applications, including co-staining with GFP and nuclear dyes such as DAPI. Upon cellular entry, Tubulite™ Red is hydrolyzed by intracellular esterases, removing its lipophilic blocking group to produce a charged, membrane-impermeant form that is well-retained within cells. Tubulite™ Red is not generally recommended for studies of dynamic cellular processes, as it may interfere with key cellular functions, including tubulin activity and cell division. Additionally, it is unsuitable for fixed-cell imaging, as fluorescence is lost during cell fixation.
Example protocol
AT A GLANCE
Prepare cells with test compounds at a density of 5 × 105 to 1 × 106 cells/mL
Prepare and add Tublite™ Red working solution to cells
Incubate at 37°C for 60 minutes.
CELL PREPARATION
For each sample, prepare cells in 1 mL of warm medium or buffer at a density of 5 × 105 to 1 × 106 cells/mL.
Note: Each cell line should be individually assessed to determine its optimal cell density.
PREPARATION OF STOCK SOLUTIONS
Unless otherwise noted, all unused stock solutions should be divided into single-use aliquots and stored at -20 °C after preparation. Avoid repeated freeze-thaw cycles
Add 100 µL of DMSO (not provided) to the Tublite™ Red vial and mix thoroughly.
Note: Aliquot and store any unused Tublite™ Red stock solution at -20°C. Avoid multiple freeze-thaw cycles.
PREPARATION OF WORKING SOLUTION
To prepare a 1X Tubulite™ Red working solution, add 10 µL of Tublite™ Red stock solution and 1 mM ReadiUse™ Probenecid (AAT Cat# 20061, not provided) to 1 mL of HHBS [Hanks' Buffer with 20 mM Hepes] (AAT Cat# 20011, not provided) or your preferred buffer. Mix thoroughly.
Note: For best results, we recommend preparing a fresh Tublite™ Red working solution each time you use it. The working solution remains stable for a few hours.
Note: The calculations above assume that 100 µL of working solution will be used for each slide or sample. Please adjust the concentrations of Tublite™ Red and ReadiUse™ probenecid to match your specific staining and cell conditions.
SAMPLE EXPERIMENTAL PROTOCOL
Prepare cell samples as needed.
Remove the cell growth medium, then wash the cells with PBS (not included) or another buffer of your choice.
Add 100 µL of Tublite™ Red working solution to the cells, then place them in a 37°C incubator for 60 minutes.
Note: The incubation time will vary based on the specific cell type and cell concentration. Be sure to adjust the incubation time to best suit each experiment.
Remove the working solution and wash the cells twice with PBS or a preferred buffer.
Cover the cells with HHBS (or a buffer of your choice) containing 1 mM probenecid. Then, use a fluorescence microscope equipped with a Cy3 filter set to monitor the fluorescence intensity.
Product family
| Name | Excitation (nm) | Emission (nm) |
| Tubulite™ Deep Red *Cell-Permeable* | 653 | 668 |
