Tide Fluor™ 5WS succinimidyl ester [TF5WS SE]*Superior replacement for Cy5*
Tide Fluor™ 5WS (TF5WS) family has the spectral properties essentially identical to those of Cy5. Compared to Cy5 probes TF5WS family has much stronger fluorescence and higher photostability. Additionally their fluorescence is pH-independent from pH 3 to 11. These characteristics make this new dye family a superior alternative to Cy5. TF5WS-labeled peptides and nucleotides exhibit much stronger fluorescence and higher photostability than the ones labeled with Cy5. In pairing with our Tide Quencher™ 5 (TQ5), a variety of FRET peptides and nucleotides can be developed for detecting proteases and molecular beacons with enhanced sensitivity and stability.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of Tide Fluor™ 5WS succinimidyl ester [TF5WS SE]*Superior replacement for Cy5* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
| 0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
| 1 mM | 95.206 µL | 476.032 µL | 952.064 µL | 4.76 mL | 9.521 mL |
| 5 mM | 19.041 µL | 95.206 µL | 190.413 µL | 952.064 µL | 1.904 mL |
| 10 mM | 9.521 µL | 47.603 µL | 95.206 µL | 476.032 µL | 952.064 µL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
| Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
| / | = | x | = |
Spectrum
Product family
| Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) | Quantum yield | Correction Factor (280 nm) |
| Tide Fluor™ 1 succinimidyl ester [TF1 SE]*Superior replacement for EDANS* | 341 | 447 | 20000 | 0.911 | 0.187 |
| Tide Fluor™ 2, succinimidyl ester [TF2 SE]*Superior replacement for fluorescein* | 503 | 525 | 75000 | 0.91 | 0.09 |
| Tide Fluor™ 3 succinimidyl ester [TF3 SE]*Superior replacement for Cy3* | 553 | 578 | 750001 | 0.11 | 0.179 |
| Tide Fluor™ 4, succinimidyl ester [TF4 SE]*Superior replacement for ROX and Texas Red* | 577 | 602 | 90000 | 0.771 | 0.436 |
| Tide Fluor™ 6WS succinimidyl ester [TF6WS SE]*Superior replacement for Cy5.5* | 682 | 701 | 220000 | 0.271 | 0.101 |
| Tide Fluor™ 7WS, succinimidyl ester [TF7WS SE]*Superior replacement for Cy7* | 756 | 780 | 275000 | 0.31 | 0.049 |
| Tide Fluor™ 8WS, succinimidyl ester [TF8WS SE]*Near Infrared Emission* | 785 | 801 | 250000 | 0.211 | 0.109 |
| Tide Fluor™ 3WS succinimidyl ester [TF3WS SE] *Superior replacement for Cy3* | 550 | 563 | 150000 | 0.151 | 0.079 |
| Tide Fluor™ 2WS succinimidyl ester [TF2WS SE] *Superior replacement for FITC* | 491 | 516 | 75000 | 0.91 | 0.11 |
Show More (1) | |||||
Citations
View all 10 citations: Citation Explorer
Inhibiting fibronectin polymerization alleviates kidney injury due to ischemia/reperfusion
Authors: Bowers, Stephanie LK and Davis-Rodriguez, Stephanie and Thomas, Zachary M and Rudomanova, Valeriia and Bacon, W Clark and Beiersdorfer, Alex and Ma, Qing and Devarajan, Prasad and Blaxall, Burns C
Journal: American Journal of Physiology-Renal Physiology (2019)
Authors: Bowers, Stephanie LK and Davis-Rodriguez, Stephanie and Thomas, Zachary M and Rudomanova, Valeriia and Bacon, W Clark and Beiersdorfer, Alex and Ma, Qing and Devarajan, Prasad and Blaxall, Burns C
Journal: American Journal of Physiology-Renal Physiology (2019)
A mechanistic model to predict effects of cathepsin B and cystatin C on β-amyloid aggregation and degradation
Authors: Perlenfein, Tyler J and Murphy, Regina M
Journal: Journal of Biological Chemistry (2017): jbc--M117
Authors: Perlenfein, Tyler J and Murphy, Regina M
Journal: Journal of Biological Chemistry (2017): jbc--M117
Real-Time Detection of a Self-Replicating RNA Enzyme
Authors: Olea, Charles and Joyce, Gerald F
Journal: Molecules (2016): 1310
Authors: Olea, Charles and Joyce, Gerald F
Journal: Molecules (2016): 1310
Maternal serum glycosylated fibronectin as a point-of-care biomarker for assessment of preeclampsia
Authors: Rasanen, Juha and Quinn, Matthew J and Laurie, Amber and Bean, Eric and Roberts, Charles T and Nagalla, Srinivasa R and Gravett, Michael G
Journal: American journal of obstetrics and gynecology (2015): 82--e1
Authors: Rasanen, Juha and Quinn, Matthew J and Laurie, Amber and Bean, Eric and Roberts, Charles T and Nagalla, Srinivasa R and Gravett, Michael G
Journal: American journal of obstetrics and gynecology (2015): 82--e1
Development of Multi-Parametric/Multimodal Spectroscopy Apparatus for Characterization of Functional Interfaces
Authors: Zhou, Lang and Arugula, Mary and Easley, Christopher J and Shannon, Curtis and Simonian, Aleks and r, undefined
Journal: ECS Transactions (2015): 9--16
Authors: Zhou, Lang and Arugula, Mary and Easley, Christopher J and Shannon, Curtis and Simonian, Aleks and r, undefined
Journal: ECS Transactions (2015): 9--16
References
View all 25 references: Citation Explorer
Rapid detection and quantification of Propionibacteriaceae
Authors: Goldschmidt P, Ferreira CC, Degorge S, Benallaoua D, Boutboul S, Laroche L, Batellier L, Chaumeil C.
Journal: Br J Ophthalmol (2009): 258
Authors: Goldschmidt P, Ferreira CC, Degorge S, Benallaoua D, Boutboul S, Laroche L, Batellier L, Chaumeil C.
Journal: Br J Ophthalmol (2009): 258
Time-resolved FRET method for typing polymorphic alleles of the human leukocyte antigen system by using a single DNA probe
Authors: Andreoni A, Bondani M, Nardo L.
Journal: Photochem Photobiol Sci (2009): 1202
Authors: Andreoni A, Bondani M, Nardo L.
Journal: Photochem Photobiol Sci (2009): 1202
Tumor-specific detection of an optically targeted antibody combined with a quencher-conjugated neutravidin "quencher-chaser": a dual "quench and chase" strategy to improve target to nontarget ratios for molecular imaging of cancer
Authors: Ogawa M, Kosaka N, Choyke PL, Kobayashi H.
Journal: Bioconjug Chem (2009): 147
Authors: Ogawa M, Kosaka N, Choyke PL, Kobayashi H.
Journal: Bioconjug Chem (2009): 147
The detection of platelet derived growth factor using decoupling of quencher-oligonucleotide from aptamer/quantum dot bioconjugates
Authors: Kim GI, Kim KW, Oh MK, Sung YM.
Journal: Nanotechnology (2009): 175503
Authors: Kim GI, Kim KW, Oh MK, Sung YM.
Journal: Nanotechnology (2009): 175503
Development of a cell-based hepatitis C virus infection fluorescent resonance energy transfer assay for high-throughput antiviral compound screening
Authors: Yu X, Sainz B, Jr., Uprichard SL.
Journal: Antimicrob Agents Chemother (2009): 4311
Authors: Yu X, Sainz B, Jr., Uprichard SL.
Journal: Antimicrob Agents Chemother (2009): 4311
