MagaDye™ 588-ddTTP

Ordering information

Price
Catalog Number
Unit Size
Quantity

Add to cart

Additional ordering information

Telephone	1-800-990-8053
Fax	1-800-609-2943
Email	sales@aatbio.com
International	See distributors
Bulk request	Inquire
Custom size	Inquire
Shipping	Standard overnight for United States, inquire for international

Physical properties

Molecular weight	~1900
Solvent	Water

Spectral properties

Absorbance (nm)	498
Excitation (nm)	498
Emission (nm)	588

Storage, safety and handling

H-phrase	H303, H313, H333
Hazard symbol	XN
Intended use	Research Use Only (RUO)
R-phrase	R20, R21, R22
Storage	Freeze (< -15 °C); Minimize light exposure
UNSPSC	12171501

Overview SDS Protocol

Molecular weight

~1900

Absorbance (nm)

498

Excitation (nm)

498

Emission (nm)

588

Sanger sequencing, also known as the chain termination method, is a technique for DNA sequencing based upon the selective incorporation of chain-terminating dideoxynucleotides (ddNTPs) by DNA polymerase. It was developed by Frederick Sanger and colleagues in 1977. Although the newer NGS technologies are becoming common in clinical research labs due to their higher throughput capabilities and lower costs per sample, Sanger sequencing with 99.99% accuracy is still the “gold standard” for clinical research sequencing. The four distinct fluorescent ddNTPs (labeled with BigDye®, BigDye® is the trademark of ThermoFisher) are the critical components for performing Sanger sequencing. MagaDye™ 588-ddTTP is equivalent to BigDye dTMR color with almost identical spectra.

Spectrum

Open in Advanced Spectrum Viewer

Spectral properties

Absorbance (nm)	498
Excitation (nm)	498
Emission (nm)	588

Images

Figure 1. Chemical structure for MagaDye™ 588-ddTTP.
