Calculator
5-CR6G, SE [5-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer*
5-CR6G, SE is amine-reactive derivative of 5-CR6G. It is preferred for some complicated biological applications where reproducibility is more critical than material cost since the minor positional difference between 5-CR6G and 6-CR6G might significantly affect some biological properties of the underlying conjugates.
Calculators
Common stock solution preparation
Table 1. Volume of DMSO needed to reconstitute specific mass of 5-CR6G, SE [5-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer* to given concentration. Note that volume is only for preparing stock solution. Refer to sample experimental protocol for appropriate experimental/physiological buffers.
| 0.1 mg | 0.5 mg | 1 mg | 5 mg | 10 mg | |
| 1 mM | 179.989 µL | 899.944 µL | 1.8 mL | 8.999 mL | 17.999 mL |
| 5 mM | 35.998 µL | 179.989 µL | 359.978 µL | 1.8 mL | 3.6 mL |
| 10 mM | 17.999 µL | 89.994 µL | 179.989 µL | 899.944 µL | 1.8 mL |
Molarity calculator
Enter any two values (mass, volume, concentration) to calculate the third.
| Mass (Calculate) | Molecular weight | Volume (Calculate) | Concentration (Calculate) | Moles | ||||
| / | = | x | = |
Spectrum
Product family
| Name | Excitation (nm) | Emission (nm) | Extinction coefficient (cm -1 M -1) | Correction Factor (260 nm) | Correction Factor (280 nm) |
| 5(6)-CR6G [5-(and 6)-Carboxyrhodamine 6G] | 522 | 546 | 94000 | 0.24 | 0.214 |
| 6-CR6G, SE [6-Carboxyrhodamine 6G, succinimidyl ester] *Single isomer* | 522 | 546 | 94000 | 0.24 | 0.214 |
| 5-TAMRA, SE [5-Carboxytetramethylrhodamine, succinimidyl ester] *CAS#: 150810-68-7* | 552 | 578 | 90000 | 0.32 | 0.178 |
| 5-ROX, SE [5-Carboxy-X-rhodamine, succinimidyl ester] *CAS 209734-74-7* | 578 | 604 | 82000 | - | 0.168 |
| 5-FAM, SE [5-Carboxyfluorescein, succinimidyl ester] *CAS 92557-80-7* | 493 | 517 | 83000 | 0.32 | 0.178 |
Citations
View all 1 citations: Citation Explorer
Rotational motion of rhodamine 6G tethered to actin through oligo (ethylene glycol) linkers studied by frequency-domain fluorescence anisotropy
Authors: Wazawa, Tetsuichi and Morimoto, Nobuyuki and Nagai, Takeharu and Suzuki, Makoto
Journal: Biophysics and Physicobiology (2015): 87--102
Authors: Wazawa, Tetsuichi and Morimoto, Nobuyuki and Nagai, Takeharu and Suzuki, Makoto
Journal: Biophysics and Physicobiology (2015): 87--102
References
View all 6 references: Citation Explorer
Four-color DNA sequencing by synthesis on a chip using photocleavable fluorescent nucleotides
Authors: Seo TS, Bai X, Kim DH, Meng Q, Shi S, Ruparel H, Li Z, Turro NJ, Ju J.
Journal: Proc Natl Acad Sci U S A (2005): 5926
Authors: Seo TS, Bai X, Kim DH, Meng Q, Shi S, Ruparel H, Li Z, Turro NJ, Ju J.
Journal: Proc Natl Acad Sci U S A (2005): 5926
Modifying the adsorption behavior of polyamidoamine dendrimers at silica surfaces investigated by total internal reflection fluorescence correlation spectroscopy
Authors: McCain KS, Schluesche P, Harris JM.
Journal: Anal Chem (2004): 930
Authors: McCain KS, Schluesche P, Harris JM.
Journal: Anal Chem (2004): 930
High-power blue/UV light-emitting diodes as excitation sources for sensitive detection
Authors: Kuo JS, Kuyper CL, Allen PB, Fiorini GS, Chiu DT.
Journal: Electrophoresis (2004): 3796
Authors: Kuo JS, Kuyper CL, Allen PB, Fiorini GS, Chiu DT.
Journal: Electrophoresis (2004): 3796
Fluorescence resonance energy transfer (FRET) and competing processes in donor-acceptor substituted DNA strands: a comparative study of ensemble and single-molecule data
Authors: Dietrich A, Buschmann V, Muller C, Sauer M.
Journal: J Biotechnol (2002): 211
Authors: Dietrich A, Buschmann V, Muller C, Sauer M.
Journal: J Biotechnol (2002): 211
Efficient and high fidelity incorporation of dye-terminators by a novel archaeal DNA polymerase mutant
Authors: Arezi B, Hansen CJ, Hogrefe HH.
Journal: J Mol Biol (2002): 719
Authors: Arezi B, Hansen CJ, Hogrefe HH.
Journal: J Mol Biol (2002): 719
